Car alarm system with back up battery siren, 2 points immobolizers, black wires 5" Tacho Meter with Shiftlight Brand New (never used) in the box from manufacturer, TUV standard This unit comes with 8 digits Green display and enunciators 3 digit voltage output display Continuous adjustment of amplitude, Frequency and pulse duty cycle * Brand New Function Signal Generator * Power cable (Australian plug) Output Frequency Range (Seven ranges) 0.2 Hz ~ 2 Hz ~ 20 Hz ~ 200 Hz ~ 2 KHz ~ 20 KHz ~ 200 KHz ~ 2 MHz Sine, Square, Rectangle, Saw tooth, and Triangle waves Output signal impedance: 50 ohm Output signal amplitude (peak ~ peak value) * Non-attenuate 2Vp-p - 20Vp-p +/- 20% continuously adjustable * Attenuate 20 dB 0.2Vp-p - 2.0Vp-p +/- 20% continuously adjustable * Attenuate 40 dB 20mVp-p - 200mVp-p +/- 20% continuously adjustable * The figures are tested with load 1 M ohm. The amplitude of output signal will be half of the value with 50 ohm Function output symmetry adjust scope * Sine wave distortion: < 2% * Triangle wave linear: 99% (10 ~ 90 % of output amplitude) * Square wave rise edge time; less than 100ns (10 ~ 90 % of output amplitude) * Square wave fall edge time; less than 100ns (10 ~ 90 % of output amplitude) * Square wave rise and fall pulse less than or equal to 5% Vo (50 ohm load) * The test condition 10 KHz, 5V p-p, warm up for 20m Output signal frequency stability (Only for 50 ohm load. At 1M load, the real output amplitude is double of the displaying value): * Display digits: 2/3 digits (decimal point automatic select place). * Display units Vp-p or mVp-p. * Display error: Vo 10% +/- 1d (Vo refers to the true value of output signal) * Resolution: non-attenuate 0.2Vp-p Display effective digit: four of five digits. Frequency stability: +/- 5x10-5 Dimension: 270 mm X 215 mm X 100 mm Working temperature: 0 ~40 degree C (New signal generator 0.2HZ-2MHZ, 5 types signals, hq is the responsibility of James Booth) |
Jbooth@cedar--rapids.com (James Booth) for more information.
