Tektronix 7A42 Plug In Service Manuals Vol 1 and 2 in both Very High and in Standard Resolution PDFs on CD (No need to "email for samples," so no need to worry about getting sold to a SPAM list!) (Please read FAQ or "About Me" Page) Volume One includes operations information in the General Info section, plus maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams. Volume Two consists of signature analysis tables. SCAN PARAMETERS (Very High Res PDF): Text with photos: 600dpi grayscale (contrast adjusted) Text with Drawings: 600dpi black and white Schematics: 600dpi black and white Schematics and board overlays with color notes: 256 colors 600dpi Please be aware that our scans are actually made at the specified resolution, so are often (as in this case) much larger than "The Marketer's" falsified offerings of the same thing. The very high res (600/300 dpi) scan of Vol 1 is 490MB in size, and that of Vol 2 is 92MB. Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. In this case, Vol 1 comes in at 46MB, and Vol 2 at 9MB. Click HERE to see a set of sixty-two 7000 series Plug-In Manuals, and click HERE to see a set of thirty-eight TM500 series Plug-In Manuals. "AND IF THAT'S NOT ENOUGH FOR YOU": As "bonus" material, includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF at no additional charge! (Tek 7A42 service manuals 2 volume set - no advertising is the responsibility of Teri Parks) |
tparks@cedar--rapids.com (Teri Parks) for more information.
