Some flyers at the beginning of the manual. INSTALLATION INSTRUCTIONS – some sections of this include: Installation Instructions for Roof Top Units – 6767 and 6769 Delta T Series Models A and B; 6777 and 6779 Delta TX Series Models A and B Installed with Ceiling Assemblies 6769A714 “Cooling Only†and 6769A716 “Heat/Cool†– 15 pages long. Operation and Maintenance Instructions for Roof Top Units – 6767 and 6769 Delta T Series Models A and B; 6777 and 6779 Delta TX Series Models A and B Installed with Ceiling Assemblies 6769A714 “Cooling Only†and 6769A716 “Heat/Cool†– 11 pages long. Installation Instructions for 6769-9911 Control Update Kit – 7 pages long. Installation Instructions for Roof Top Models 6767 and 6769 Delta T Series; 6777 and 6779 Delta TX Series Installed with Ceiling Assemblies 6769-714 “Cooling Only†and 6769-716 “Heat/Cool†– 15 pages long. Installation Instructions for Roof Top Models 6757 Mach 1 Rotary Series; 6759 Mach 3 Rotary Series Installed with Ceiling Assemblies 6759B716 “Heat/Cool†and 6759B714 “Cooling Only†– 11 pages long. Installation Instructions for Deluxe Models 6757 Mach 1 Rotary Series; 6759 Mach 3 Rotary Series “Elect-A-Heat†Option Installed with Ceiling Assemblies 6759A716 “Heat/Cool†and 6759A714 “Cooling Only†– 11 pages long. Installation Instructions for Deluxe Models 6757 Mach 1 Rotary Series; 6759 Mach 3 Rotary Series “Elect-A-Heat†Option Installed with Ceiling Assemblies 6759-716 “Heat/Cool†and 6759-714 “Cooling Only†– 11 pages long. Installation Instructions for Recreational Vehicle Air Conditioners Models 6747 Mach 1 Rotary Series; 6749 Mach 3 Rotary Series “Elect-A-Heat†Option Installed with Ceiling Assemblies 6723A713 and 6723A716 “Heat/Cool†and 6723A714“Cooling Only†– 11 pages long. Installation Instructions for Roof Top Model 6727A Series Rotary Mini-Mach Installed with Ceiling Assemblies 6727-714 “Cooling Onlyâ€; 6727A714 “Cooling Onlyâ€; 6759B714 “Cooling Onlyâ€; 6759B716 “Heat/Cool†– 15 pages long. Installation Instructions for Model 6727A Series Rotary Mini-Mach Installed with 6727-714 “Cooling Only†Ceiling Assembly; 6723A714 “Cooling Only†Ceiling Assembly; 6723A716 “Heat/Cool†Ceiling Assembly – 19 pages long. Installation Instructions for 6770A & B Series Roughneck Off-Road Vehicle Air Conditioning Used with 6770A716 “Heat/Cool†Ceiling Assemblies; 6770A714 “Cooling Only†Ceiling Assemblies Both with Continuous Cooling Feature – 11 pages long. Installation Instructions for 6770 Series Roughneck Off-Road Vehicle Air Conditioning Used with 6770-716 “Heat/Cool†Ceiling Assemblies; 6770-714 “Cooling Only†Ceiling Assemblies Both with Continuous Cooling Feature – 11 pages long. ACCESSORIES - some sections of this include: Installation Instructions 6769-7261 Electric Heat Conversion Kit – 7 pages long. Installation Instructions 6759-7361 Electric Heat Conversion Kit – 7 pages long. Installation Instructions 6759-7261 Electric Heat Conversion Kit – 7 pages long. Installation Instructions – 1 page long. Installation Instructions – 6707-6481 Van Gasket Package - 1 page long. Installation Instructions – 6759-7441 Remote Control Box - 3 pages long. PARTS - some sections of this include: Set Up and Operation Instructions 6757-7201 Field Service Test Device – 4 pages. Repair Parts List Coleman Delta TX RV Air Conditioner Model Number 6777 and 6779 – 3 pages. Repair Parts List Coleman Delta T RV Air Conditioner Model Number 6767 and 6769 – 3 pages. Repair Parts List Coleman RV Air Conditioners Two-Speed Rotary Model Number 6757B TSR (Mach 1) and 6759B TSR (Mach 3) – 3 pages. Repair Parts List Coleman RV Air Conditioners Two-Speed Rotary Model Number 6757A TSR (Mach 1) and 6759A TSR (Mach 3) – 3 pages. Repair Parts List Coleman RV Air Conditioners Two-Speed Rotary Model Number 6757 TSR (Mach 1) and 6759 TSR (Mach 3) – 8 pages. Repair Parts List Coleman RV Air Conditioners Rotary Model Number 6747 (Mach 1), 6749 (Mach 3), 6749R Mach 3 – 3 pages. Repair Parts List Mini-Mach Rotary Model Number 6727A – 4 pages. Repair Parts List Mini-Mach Rotary Model Number 6727 –3 pages. Repair Parts List Roughneck RV Air Conditioners Two-Speed Rotary Model Number 6770 – 3 pages. WARRANTY - some sections of this include: TECHNICAL SERVICES BULLETINS – 7 pages. SERVICE MANUALS - some sections of this include: Service Guide Deluxe Models 6757 Mach 1 Rotary Series and 6759 Mach 3 Rotary Series – 7 pages. Rotorex Compressor Company Service Training Manual for Rotary Compressors – 22 pages. Service Manual 6700 Series Mach I, Mach II and Mach III – 23 pages. Data-tech Education/Training Series proper use of Dial-a-charge Refrigerant Charging Cylinders – 9 pages. COOLING PERFORMANCE DATA – 11 pages. REFRIGERATION CIRCUIT – 5 pages. Please note that there is a Tests tab but there is nothing behind it. If you work on Coleman heating or air conditioning units for RV’s here’s a valuable manual to have! (Coleman rv air conditioner / heating manual is the responsibility of Cathryn Wheeler) |
cathryn-wheeler@cedar--rapids.com (Cathryn Wheeler) for more information.
