http:// /images/islogo_lg.gif Pratt & Whitney Vertical Shaper Pratt & Whitney Vertical Shaper Max. Dist. Table top to End of Ram: 15" Vertical Adjustment of Ram: 10" Column Face to Tool Post Seat: 18-3/4" Column Face to Table Centerline, Max: 30" Rotary Table Diameter: 19-3/4" Longitudinal Table Travel: 25" Transverse Table Travel: 20" Angular Adjustment of Ram: 0 - 5 Deg. Tool Size for Tool Post: 3/4" x 1-1/2" Cutting Speed of Ram: 33 116 SPM Table Feed Rates: .0027" - .0243" Rotary Table Power Feed Rates: .009" - .085" Machine Weight, Approx.: 4,600 Lbs. 19-3/4" Diameter Rotary Table 3 HP Motor Drive 220/440/3/60 All Items Subject to Prior Sale Be Sure to Verify Specs & Condition Prior to Purchasing CONTACT US: We are available to answer your calls and inquires, Monday thru Friday, 8am - 5pm, at 860.828.3541, or you can email us at juanwalter@cedar--rapids.com http:// /images/building.jpg (Pratt & whitney vertical shaper is the responsibility of Juan Walter) |
