http:// /images/islogo_lg.gif Pratt & Whitney CNC Vertical Jig Borer Pratt & Whitney 4 EA CNC Vertical Jig Bore Model No. 4EA, Serial No. 35109, New 1969 Table Working Surface: 36" x 78" Built-In Rotary Table Diameter, C-Axis: 48" Longitudinal Travel, X-Axis: 60" Transverse Travel, Y-Axis: 36" Vertical Travel, Head on Column: 54" Max. Distance Spindle Nose to Table Top: 70" Distance Column Ways to Spindle Center: 50" Spindle Speeds (16): 40 - 1834 RPM Spindle Feed, Per Revolution: .0005" - .0150" Table & Carriage Feed Rates, Variable: 0 - 30 IPM Table & Carriage Rapid Traverse Rate: 150 IPM Rotary Table Feed Rates, Variable: 0 - 65 Deg./Min. Rotary Table Rapid Traverse Rate: 2-1/2 RPM Max. Recommended Workload Weight: 5,000 Lbs. Machine Overall Weight, Approx.: 55,000 Lbs. GE/ Mark Century 1050 CNC Control Anilam Mini Wizard 2-Axis DRO 5 HP (4) Speed Spindle Motor 440/3/60 All Items Subject to Prior Sale Be Sure to Verify Specs & Condition Prior to Purchasing CONTACT US: We are available to answer your calls and inquires, Monday thru Friday, 8am - 5pm, at 860.828.3541, or you can email us at georgia-emerson@cedar--rapids.com http:// /images/building.jpg (Pratt & whitney cnc vertical jig borer is the responsibility of Georgia Emerson) |
georgia-emerson@cedar--rapids.com (Georgia Emerson) for more information.
