Pro Video Leader Model 5872A Vector Waveform Monitor The 5872A is a combination waveform/vectorscope; it accepts two composite signals and will overlay the signals so they can be compared or viewed simultaneously. Differential Gain/Differential Phase measurements are possible with this unit. 9 presets can be set for routine tests or multiple users. Displays from both channels, waveform and vectorscope can be displayed simultaneously for comparison and monitoring. A full raster line select is offered with lines chosen from fields 1/3, 2/4 or all fields. This signal facilitates high resolution measurements of differential phase and differential gain. Chroma and IRE filters may be inserted on a full-time or line-shared basis. Along with AC operation, this unit will function using 12 VDC through the 4-Pin XLR connector. Worldwide voltages from 90 to 250 VAC 48 to 440 Hz can be utilized for studio operation of this unit. Composite Video x2, Looping, NTSC, on BNC connectors External Reference, Looping, NTSC, Sync and burst or Black Burst, 286 mv, on BNC connectors Composite Video x2, Loop Out, NTSC, on BNC connectors External Reference, Loop Out, NTSC, Sync and burst or Black Burst, 286 mv, on BNC connectors Picture Monitor Out, NTSC, on a BNC connector Internal Graticule Illumination 12 VDC from external source on a 4-Pin XLR connector FREE scheduling, supersized images Make your listings stand out with Smart Services for Smart Sellers FREE scheduling, supersized images (Pro video leader model 5872A vector waveform monitor is the responsibility of Audra Clay) |
