MAZAK MODEL QT28N CNC LATHE* Maximum Swing: 20" Maximum Swing Over Cross Slide: 15.75" Maximum Cutting Diameter: 12.6" Maximum Cutting Length: " Spindle Speeds (Infinitely Variable): 30 - 2500 RPM Spindle HP: 25/30 Spindle Nose: A2-11 Spindle Bore: 4" X-Axis Travel: 10.43" Z-Axis Travel: 40.16" Rapid Traverse Rate: X-Axis - 707 IPM; Z-Axis - 945 IPM EQUIPPED WITH: Mazatrol T32-2 CNC Control 8 or 16-Position Turret Coolant System Chip Conveyor SWM Air CHuck with 4.1" Bore Approximate Overall Dimensions: 140" L-R x 75" F-B x 75" H Approximate Weight: 12,000 Lbs. Serial Number: 104179 (New 1992) * PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION Email us at margret.pollard@cedar--rapids.com Call our Sales Staff at 1-(***)-254-8808 Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes. Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power. 1-(***)-427-3333 (outside US & Canada) Email: margret.pollard@cedar--rapids.com (Mazak qt 28N cnc lathe is the responsibility of Margret Pollard) |
margret.pollard@cedar--rapids.com (Margret Pollard) for more information.
