"#1800, #1900 Lathe Instructions Manual" This is a reproduction, not a photocopy, of an original Logan 10" & 11" Lathes #1800 and #1900 as well as the screw cutting and turret lathes Instructions Manual. This manual contains information on setup, lubrication, maintenance, and controls for this lathe. This would be a great manual for anyone who owns one of these lathes. Part Location Diagram...........................................1 Setting Up the Lathe..............................................2 Mounting the Motor...............................................2 Adjusting the Belts.................................................3 Headstock Operations...........................................3 Back Gear Operations...........................................4 Spindle Speeds......................................................4 Tailstock Operations..............................................5 Power Feed Operations.........................................6 Apron Operations..................................................7 Friction Clutch Operations.....................................8 Saddle Operations.................................................8 Compound Rest Operations...................................8 Lubrication Instructions..........................................9 Turret Assembly..................................................10 Motor & Switch Wiring Diagram..........................11 I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench. Be sure to add my store to your favorites list! I am adding new manuals all the time. PLEASE READ the return policy and COMPLETE description of the manual. Because of the nature of this product, I do not accept any returns or exchanges under any circumstances. If you have any questions, email me or send me a picture first. I (Logan 10" & 11" lathe #1800 #1900 instructions manual is the responsibility of Cecelia Terry) |
