TM115 TM125 TM135 TM150 and TM165 Tractor 60455061 - aprox 2000 PAGES - 01/2000 CONTENTS Complete repair and maintenance procedures for TM Series Tractors in 12 Chapters includes repair manual supplements .01 and .02 which have been installed * 1 - General instructions and health and safety * 10-000 Specifications * 10-001 Engine removal and installation * 10-100 Engine disassembly and overhaul * 10-200 Fuel system components * 10-400 Cooling system components * 18-000 Specifications * 18-110 Clutch removal-installation * 18-104 Hydraulic control * 21 TRANSMISSION SYSTEM * 1 - Range Command Transmission Overhaul * 2 - Range Command Transmission Fault Finding * 3 - Dual Command Transmission Overhaul * 4 - Dual Command Transmission Fault Finding * 5 - Shuttle Command Transmission * 6 - Power Command Transmission * 23 DRIVE LINES (TRANSFER BOX) * 1 - Four Wheel Drive Axle Transfer Box * 25 FRONT AXLE MECHANICAL TRANSMISSION * 1 - Four Wheel drive Front Axle * 2 - Terraglide (Front Axle Suspension) * 27 MECHANICAL REAR WHEEL DRIVE * 1 - Power Take Off system * 2 - Front Lift and Power Take Off * 1 - Tractor Brakes * 2 - Pneumatic Trailer brakes arranged in the following section order * 35 HYDRAULIC SYSTEMS * 2 - Hydraulic Pump Assembly with Variable Displacement Closed Centre Load Sensing (CCLS) * 3 - Fixed Displacement Gear Type Pumps * 4 - Hydraulic Lift Assembly with Electronic draft Control * 5 - Hydraulic Lift Assembly with Top Link Sensing * 6 - Remote Control Valves with Closed Centre Hydraulics * 7 - Remote Control Valves with Open Centre Hydraulics * 8 - Hydraulic Trailer Brakes * 10 - Hydraulic Pressure Testing * 1 - Hydrostatic Steering Systems * 1 - Two Wheel Drive Axle * 1 - Air Conditioning * 55 ELECTRICAL SYSTEM * 1 - Electrical Introduction * 2 - Electronic Management Unit * 3 - Electronic Instrument Cluster * 4 - Analogue Electronic Instrument Cluster * 5 - Analogue Instrument Cluster * 6 - Starting System * 7 - Charging System * 9 - Wiring Diagrams * 10 - Electrical Component Testing * 11 - Diagnostic 'H' Routines * 12 - Connectors and Harness IF THE BOOK YOU ARE LOOKING FOR IS NOT LISTED ASK US IF WE CAN LIST IT FOR YOU (New holland nh TM115 thru TM165 tractor workshop manual is the responsibility of Julian Dickson) |
juliandickson@cedar--rapids.com (Julian Dickson) for more information.
