Tristate Sales is pleased to offer an affordable and easy option for maintenance and testing of Cat. 5/5E/6 cable. The Lancat V One Way Test and Maintenance System boasts an easy user interface with no confusing menus to scroll through. Simply turn the dial, plug the included One-Way remote to the other end of your cabling, and you are off to your first test. The easy-to-read display is back-lit for darkened lighting conditions. All the important functions that are needed to perform real-world maintenance and testing of Category 5/5E/6 wiring are included. Under Autotest, the LANcat V performs Wire Map, Near-End-Crosstalk (NEXT), Attenuation, Length, Resistance, Characteristic Impedance, and Attenuation-to-Crosstalk Ratio (ACR) tests for cable Cat 5 certification. Each test can also be run individually for diagnostic troubleshooting. Impedance Test detects up to three impedance discontinuities - useful for isolating cable damage. Under Quick CheckTM mode, an abbreviated test sequence of Wire Map, Length, NEXT and Attenuation is completed in less than 20 seconds for quick installation verification. * CABLE TESTS: The LANcat V certifies UTP and STP to EIA/TIA Standards. It also certifies coaxial, UTP and STP to IEEE and EC/ISO requirements. Tests performed include: 1. Cable Length (via TDR) 3. Near End Crosstalk (NEXT) 5. Attenuation-to-Crosstalk Ratio (ACR) 8. Traffic (Ethernet Only) 9. Characteristic Impedance * Range: 4000ft (1220m) Coax, 3000ft (915m) UTP & STP * CALIBRATE NVP (Based on cable of known length) * WIRE MAPPING (Twisted Pair Wiring Only) Displays Following Errors: Miswired Pairs, Shorts, Opens, Shorted Pairs, Crossed Pairs and Split Pairs. Includes test of shield. * NEAR-END-CROSSTALK (NEXT) (Tests all six pair combinations) * Frequency Range: 0.77MHz to 10OMHz * Measurement Range: 0 to -6OdB * ATTENUATION (Tests all four pair combinations one way) * Frequency Range: 0.77MHz to 10OMHz * Measurement Range: 0 to -6OdB * ATTENUATION-TO-CROSSTALK RATIO: ACR is calculated for each pair over the full frequency range per test specification selected. * RESISTANCE: DC resistance of each conductor is measured. * IMPULSE NOISE: Counts impulse noise hits above user defined threshold. * Threshold.- User defined, 1OOmV to 5OOmV peak (26OmV default) * Options: RJ45 female, BNC coax or STP (IBM Type 1) * Memory. Storage space for 500 test results. 1. RJ45 plug connector adapter 3. Batteries, 1 set, installed 4. Battery eliminator, AC adapter (Datacom lancat v one way test & maintenance system is the responsibility of Caitlin Hendricks) |
