Hi-resolution, reproduction grade scan of the Tektronix R7903 SERVICE MANUAL. 312-Pages, scanned from the original Tektronix manual in PDF file format (215MB) . Tektronix part number 070-1464-00, S/N directly mentioned B010100 - B212983, Later revised printing of December 1986 * General Operating Instructions * Electrical & Mechanical Parts lists * Schematics & Circuit Board Part Locators views * Electronic page numbers = original manual page numbers (1-1,1-2, etc) * 600dpi schematic scans for detail printing (8.5 x 11 scans of large foldouts with ample over lap for piecing when printed) And what good is a 7000 series scope without plug-ins? So here you go ! 60 manuals, covering 52 plug-ins, see the complete list below. (52 service manuals + 6 operators manuals + 2 special application manuals. All of these manuals were scanned from original commercial Tektronix manuals (these are NOT government TM manuals) * ALL SERVICE MANUALS CONTAIN, BASIC OPERATION, SPECIFICATIONS, MAINTENANCE, CALIBRATION, SCHEMATICS, PARTS LISTS AND LOCATION DIAGRAMS * ALL MANUALS ARE TEXT SEARCHABLE (IN LIEU OF BOOKMARKING) * ALL MANUALS ARE IN PDF FORMAT ON ONE EASY TO USE CD, READABLE WITH ADOBE ACROBAT READER AND INDIVIDUAL PAGES CAN BE PRINTED FOR BENCH USE USING ADOBE. MANUALS OFFERED IN THIS COLLECTION (Tektronix R7903 + 52 plug-ins 61 manual set is the responsibility of Ricardo Peters) |
ricardopeters@cedar--rapids.com (Ricardo Peters) for more information.
