Tektronix DC509 Service and Operating Manual Why settle for just one resolution? You get them both! You get no hype here, just good value and honesty. This manual covers operations, maintenance and servicing of the Tektronix DC509 Oscilloscope Plugin. It is scanned from the original manufacturer's manual. The scans came out well, and all information available in the original manual is available here. Two PDFs of the manual are provided, in two resolutions. One is: Text with Drawings at 600dpi black and white or grayscale (content-dependent) Schematics at 600dpi black and white or grayscale (content-dependent) Text with photos at 600dpi (minimum) grayscale with contrast adjusted Schematics, overlays with color coding (if any) at 600dpi 256 colors (minimum) The other PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed. Also, I include a "foldouts.pdf" with the A3 (11x17") foldout pages from the manual scanned full-size (one piece). Please note that the foldout pages are ALSO included as A4 scans (sectioned as 8.5 x 11" pages, in other words) in the main manual. I send you both both resolutions on the CD. You'll receive the large file, plus the smaller, faster text-searchable version, plus the A3 "foldouts" file. That way, you can navigate, search and etceteras with the fast file and only use the large files when you want to print. There's no need to clutter up your drives with the file that's hundreds of megabytes in size, nor any need to spend time writing them to and from the hard drive if you aren't the sort who likes to waste space. Yet the extra-large PDF is still provided for when you need exceptional print quality. All original manual pages are supplied in both resolutions, with no pages added or ubtracted. The "main" or "very high resolution" manual as well as the smaller, faster version have both the chapter-page numbering system ("electronic manual page numbers match paper manual page numbers") and the sequential (logical) page numbering system. The very high resolution version is fully bookmarked and extensively hyperlinked, for those folk who like that, and the smaller, faster version is also text-searchable as well as fully bookmarked and extensively hyperlinked. (Tek DC509 dc 509 svc/ops manual in 2 res + A3 -and- A4 is the responsibility of Felix Russo) |
f-russo@cedar--rapids.com (Felix Russo) for more information.
