December 2004, v3.1 User Guide Introduction The University Program UP2 Education Kit was designed to meet the needs of universities teaching digital logic design with state-of-the-art development tools and programmable logic devices (PLDs). The package provides all of the necessary tools for creating and implementing digital logic designs, including the following features: * Quartus ® II Web-Edition development software * An EPF10K70 device in a 240-pin power quad flat pack (RQFP)package * An EPM7128S device in an 84-pin plastic J-lead chip carrier(PLCC) package * ByteBlaster TM II parallel port download cable The Quartus II University software contains many of the features of the commercial version of the Quartus II software including a completely integrated design flow and an intuitive graphical user interface. This software supports schematic capture and text-based hardware description language (HDL) design entry, including Verilog HDL, VHDL, and the Altera ® Hardware Description Language (AHDL TM ). It also provides design programming, compilation, and verification support for all devices supported by the Quartus II Web-Edition software including the EPM7128S, and EPF10K70 devices. The Quartus II software can be freely distributed to students for installation on their personal computers and provides instant access to online help. For information on how to install the Quartus II software on your computer, see “Software Installation†on page 17 of the user guide. The UP2 Education Board is a stand-alone experiment board based on a FLEX ® 10K device and includes a MAX ® 7000 device. When used with the Quartus II software, the board provides a superior platform for learning digital logic design using industry-standard development tools and PLDs. For More Information Go To: https://www.se.auckland.ac.nz/courses/SOFTENG461/resources/UP2Manual.pdf (UP2 education kit is the responsibility of Glenda Foster) |
G.Foster@cedar--rapids.com (Glenda Foster) for more information.
