Tektronix TDS754D Oscilloscope, 500 MHz, 4 Ch., 2 GS/s Description: The Tektronix TDS754D oscilloscope was the first in the TDS family of Digital Phosphor Oscilloscopes (DPOs). DPOs capture, store, display and analyze, in real time, three dimensions of signal information: amplitude, time and distribution of amplitude over time. The benefit of this new third dimension of information is an interpretation of the signal dynamics, including instantaneous changes and the frequency of occurrence displayed in the form of quantitative intensity information. Extensive user interface design has made the TDS754D is truly intuitive to operate and very easy to use and includes a graphical user interface with over 200 icons which help facilitate understanding and use of the advanced features. A color monitor helps rapidly distinguish between multiple waveforms and measurements. Online help provides a convenient built-in reference manual. The DPO acquisition acquires over 1,000 times more data than traditional DSOs, allowing the capture of complex signals, reducing debugging times from hours to seconds. Channels can be transparently combined to achieve higher sample rates and longer record lengths. The record length can be optionally increased to 8 M points, providing a high-resolution representation of the signal over a long period of time. The Tektronix TDS754D provides wide dynamic range, flat response, fast overdrive recovery, calibrated DC offset, 1 mV/div sensitivity, 1 ns peak detect and internal calibration. It also offers powerful and flexible triggering. In addition to basic triggering such as edge and pulse-width, this oscilloscope has several trigger modes tailored for specific design and debug applications. Logic and pulse triggers, including setup/hold, glitch, slew rate and timeout triggers, capture hard-to-catch digital design problems. The optional video trigger provides line and field selection for NTSC, PAL and HDTV standards. The optional communications trigger capability addresses needs to acquire a wide variety of AMI, CMI, NRZ and Ethernet communication signals. Other features include: * Acquires up to 100 M points/sec * 8-Bit Vertical Resolution, Over 11 Bits with Averaging and Over 13 Bits with Hi-res * 1 mV/div to 10 V/div Sensitivity * Differential Measurements * 50K Record Length on all four channels * Iomega Zip and Zip Plus Drive Compatible * 29 Automatic Measurements and Measurement Statistics * Communication Signal Analysis Including Mask Testing and SONET/SDH and Fibre Channel Optical Reference Receivers * Full GPIB Programmability * Cosmetic Condition: Very Good * Working Condition: Tested Good. * Other Comments / Notes: Includes pouch. Probes are not included, but we have some P6139A probes available for sale - please inquire. * The following options are installed: * 13: RS-232/Centronics Interface * 2F: Extended Waveform Math: Integration and differentiation * Warranty: Rest assured that your purchase includes a 3-day DOA Guarantee. If the item is DOA, you will need to notify us within 3-days of receipt. Item(s) must be returned in the same condition as received within 7 days of receipt. (See below for further details) We strongly recommend that you properly pack and insure the package against loss or damage. It is ultimately your responsibility that your returned product arrives at our location within the allotted return time frame in the same condition it was sent. (Tektronix TDS754D oscilloscope, 500 mhz, 4 ch, 2 gs/s is the responsibility of Lois Wilkinson) |
