Tektronix 7313 Storage scope w/7A18N,AM6565-u and 7B53A This 25MHz Storage Oscilloscope has been tested and works Units have not been fully tested but basically work, there is some cosmetic damage to a knob on the 7A18N amplifier as can be seen on the photographs, however this does not affect operation. Screen intensity is fairly low, but is use-able. 1 x 7B53A Dual Time Base with OPT 005 (TV) * Split screen, Bistable display * 4.9 cm/µS stored writing speed * Accepts up to three 7000-series plug-ins The 7A18N Dual-Trace Plug-In Amplifier is the basic building block of 3-trace and 4-trace operation. The unit features constant bandwidth for all deflection factors, 5 operating modes (Ch1, Ch2, ALT, CHOP, ADD), trigger source selectivity and color-keyed control grouping * Polarity of Channel 2 is selectable * Deflection Factor: 5 mV/div to 5 V/div * Input R and C: 1 Mohm within 2%; approx. 20 pF * 7B53A Dual Time Bases are recommended for use with the 7400, 7500, 7600 and Storage FAMILIES to privide bandwidth/sweep speed compatibility. Both time bases have identical characteristics except the 7B53A does not incorporate CRT READOUT These Dual Time Bases feature four sweep display modes: Normal, Intensified Delaying, Delayed and Mixed 5 ns/div to 5 s/div Calibrated Time Base AM6565-U is a Single-Channel amplifier, Local Pick up is also available at our office in Clayton South VIC 3169 with 24 Hrs Prior Notice. Building Trust in Transactons (tm) If you have any questions please contact Lily or Phone (switch) +613 9558 0004 Ext : 138 Office Hours are 9.00AM - 5.00PM (Tektronix 7313 storage scope w/7A18N,AM6565-u and 7B53A is the responsibility of Bettye Keith) |
BettyeKeith@cedar--rapids.com (Bettye Keith) for more information.
